From PCB design to mass production, Fanway delivers quick-turn PCB manufacturing services as one-stop solutions to address your diverse project requirements and accelerate your time-to-market.
Compare with FR-4, CEM-1 PCB save 30–50%.
It is easy to be formed by stamping, supports rapid production and has a short delivery time.
The dielectric constant (about 4.5@1MHz) is close to FR-4, meeting the requirements of most low-frequency circuits.
In fields such as LED lighting, it can effectively control costs while optimizing heat dissipation performance.
| Parameter | Capability |
| Minimum Trace Width | 0.2mm (8mil) |
| Minimum Drilled Hole | 0.35mm (14mil) |
| Copper Thickness | 1/2 oz – 3 oz |
| Board Thickness | 0.4mm – 3.2mm |
| Surface Finishes | HASL, ENIG, OSP |
| Flexural Strength | ~300MPa |
| Character | CEM-1 | FR-44 |
| Layer Support | Single sided layer only | Single sided layer, double sided layer, multi-layer |
| Material Cost | Low (save 30-50% than FR4) | High |
| Mechanical Strength | Fragile, low flexural strength | Higher and more durable |
| Coefficient of Thermal Expansion | Higher | Lower |
| Application | Low cost, single-layer design | High complexity, multi-layer design |
Consumer electronics: Remote controls, calculators, toys, printers;
Lighting equipment: LED light boards (such as brake lights, indicator lights), due to the need for heat dissipation and cost balance;
Industrial control: Power converters, instrument panels, relays
Household appliances and communication equipment: such as household appliances, telephone systems, solid-state drives.
