From PCB design to mass production, Fanway delivers quick-turn PCB manufacturing services as one-stop solutions to address your diverse project requirements and accelerate your time-to-market.
Support laser drilling, micro vias, and HDI.
100% electrical testing and AOI inspection.
Compliant with IPC-A-600 Class 2/3, UL 94V-0.
Prototypes finish in 24h, bulk orders finish in 5 days.
Space Efficiency: Double sided routing for compact layouts.
EMI Reduction: Ground plane optimization.
Cost-Efficiency: The best choice for middle complex prototypes and production.
Mechanical Strength: Reinforced via plating resists vibration.
Double Copper Layers: Support components and traces on both sides.
Substrate: FR-4, aluminum on optional.
Inter layer Connections: Through-hole, blind, or buried vias.
Protection: Double side solder mask and silkscreen.
Design Capabilities: Support SMT and through hole components both.
Cross layer routing reduce board size and enhances signal clarity.
Laminate preparation (double-sided CCL).
Drilling & via metallization (PTH).
Photolithography and copper etching.
Dual-side solder mask/silkscreen printing.
Surface finishing (ENIG, HASL, or Immersion Silver).
Technical Specifications
Thickness: 0.8–3.0mm (standard 1.6mm).
Copper Weight: 1–3 oz.
Trace/Space: 0.15mm (6 mil).
Min Via Diameter: 0.3mm (12 mil).
Dielectric Strength: 20 kV/mm (FR-4).
